Characteristic:
* Universal AC input/ Full range
* Low cost, high reliability
* High efficiency, low working temperature
* Built-in EMI filter
* 100% full load burn-in test
* Low ripple & noise
* Protections: short circuit/overload/over voltage

Specification:
Input Voltage-------------------------85—264V AC, 120—360V DC
Input frequency----------------------47—63Hz
Inrush current------------------------cold start, 15A at 115V, 30A at 230V
Output voltage-----------------------See the following table (CH1: ±10% adjustable)
Overload protection-----------------105%--150% rated output power, auto-recovery
Over voltage protection-------------CH1:115%---135% rated output voltage,
Setup, rise, hold up time------------800ms, 50ms, 10ms/115V AC
300ms, 50ms, 50ms/230V AC
Withstand voltage--------------------I/P—O/P, I/P—FG: 1.5KV, 1 minute
Working temperature----------------0-50℃ @ 100%, -10℃ @ 80%, 60℃ @ 60% load
Safety standards----------------------UL1950, EN60950, CB, CE
Connection-----------------------------6P/94P pitch terminal block with cover
Net weight-----------------------------0.4kg
